Chickpeas gravity table seed cleaner

  • 1 - 1 Sets
    $5,500.00
  • >=2 Sets
    $5,000.00
Model Number:
5XZ -8
Lead Time:
Quantity(Sets) 1 - 1 2 - 3 >3
Est. Time(days) 15 20 Negotiable
Report Suspicious Activity
Overview
Quick Details
Type:
Gravity Separator
Use:
Agriculture, Agriculture,Farming
After-sales Service Provided:
Engineers available to service machinery overseas
Certification:
CE ISO SGS
Place of Origin:
Hebei, China (Mainland)
Brand Name:
HELIDA
Condition:
New
Name:
gravity grain separator
Brand name:
HELIDA
Capacity:
8 ton/hour
Power:
11KW
Weight:
2200 KG
Dimension:
3700x2300x1800m
Function:
select out bad seeds,moldy kernel,insect damaged seed
Application:
grain and seeds,Paddy Wheat Maize Mung Beans Rice Grain Seed
Warranty:
24 months
Supply Ability
Supply Ability:
200 Set/Sets per Month
Packaging & Delivery
Packaging Details
Packed in wood case or naked package,according to customer's need.(If wood case,would need some packing fees)
Port
Tianjin Port
Lead Time :
Quantity(Sets) 1 - 1 2 - 3 >3
Est. Time(days) 15 20 To be negotiated
Video Description



Optional Accessories Available:
1. Additional Deck meant for small seeds, like vegetable seeds, grass seeds, flower seeds etc.
2. Vibratory feeder for non-free flowing grains.
3. Also,we could prepare canopy dust system including hood to cover part of the deck, connecting duct, cyclone dust collector with intergral fan as your want.
4. Elevator (to feed specific Gravity Separator).

Function and feature

The machine is widely used in seeds and agricutural byproducts processing.It’s excellent in grain seeds,bean seeds and other seeds selection. It can eliminate inferior grain, moth bitten seeds, rotten seeds, black-powder disease seeds, seed with glumes,sand and stones among the seeds.After sifting,the produce quality,including weight per thousand seed, bud rate, cleanliness and consistency, will be greatly improved.
The machine is practical ,flexible, efficient, user-friendly and mobile. It is reliable, stable, the shock absorbing cover is robust. This machine is technically excellent in its class in China.

This machine is to separate the material that has same size but different specific gravity.It could achieve better effect to separate materials of different specific gravity after material pre cleaning and grading.

By separating,the bud seeds,moldy grain,blighted grain,smut grain,immature grain,broken seeds and stone could be removed.Fine cleaned grain and seeds has a remarkable increase in thousand seed weight,cleanliness,germination rate and uniformity.

It is suitable for gravity separator of kinds of cereal grain coffee bean,cocoa bean,peanuts,

corn beas,beans,rice,wheat,sesame,sorghum etc



 Main structure

1.Fan motor, 2.Fan shaft,3.air casing,4.air shield,5.air adjusting handle,

6.Base seat,7.Driving motor,8.Spring support plate,9.Spring strip,10.Discharge outlet,

11.Vibrating frame,12.Vibrating screen,13.Spindle spring,14.air chamber,

15.Fixed splint,16.Eccentric gear,17.Sloping Steel Angle.

The blow type grain separating machine consists of Material feeding system,Vibrating screen system,air adjusting system and power drive system





Working principle

Gravity separator is an important equipment  for seeds and agricultural byproducts processing which could be used for variety of dry granular material processing.it is based on the action of the air flow and vibrate makes the heavy materials sink to the bottom,and them move upward by the vibration of the screen pieces,and also makes the light material float on the material surface and then flow downward.so the different material would be separated.



Technical  Parameters

Model

Capacity

(T/H)

Power

(KW)

Weight

(KG)

Dimension

(mm)

Area of sieve

(m²)

Remark

5XZ-8

8

11

2200

3700*2300*1800

4.3

blowing type








grain separator machine Application:

The bean gravity separator can be used to separate all kinds of seed and grains,such as coffee bean,cocoa bean,peanuts,corn,peas,beans,rice,wheat,sesame etc.

The bean gravity separator also has wide applications,from heavy industrial materials like glass,stone,metal and sand,to lighter agricultural seeds beans and nuts.



Packing and shipping:
